Описание
Engine
| Engine Type | Liquid-cooled, 4-stroke, single-cylinder |
|---|---|
| Compression ratio | 14.1:1 |
| Valve system | DOHC, 4 valves |
| Bore x stroke | 78.0 x 52.2 mm |
| Displacement | 249 cm³ |
| Fuel System | Fuel injection: 44 mm x 1 |
| Lubrication | Forced lubrication, semi‑dry sump |
| Starting system | Electric |
| Ignition | Digital
|
Performance & Transmission
| Transmission | 5-speed, return shift |
|---|---|
| Clutch | Wet, multi disc |
| Primary reduction ratio | 3.350 (67/20) |
| Gear ratios 1st | 2.077 (27/13) |
| Gear ratios 2nd | 1.688 (27/16) |
| Gear ratios 3rd | 1.438 (23/16) |
| Gear ratios 4th | 1.235 (21/17) |
| Gear ratios 5th | 1.045 (23/22) |
| Final drive | Chain |
| Final reduction ratio | 3.846 (50/13) |
Frame & Dimensions
| Frame type | Perimeter, aluminium |
|---|---|
| Trail | 118 mm |
| Wheel travel front | 314 mm |
| Wheel travel rear | 316 mm |
| Tyre, front | 80/100-21 51M |
| Tyre, rear | 110/90-19 62M |
| L x W x H | 2,190 x 820 x 1,270 mm |
| Steering angle L R | 42° / 42° |
| Wheel base | 1,485 mm |
| Ground clearance | 345 mm |
| Fuel capacity | 6.2 litres |
| Seat height | 960 mm |
| Curb mass | 108 kg |
Brakes & Suspension
| Front brake type | Single semi-floating petal disc |
|---|---|
| Front brake diameter | Ø 270 mm |
| Front brake caliper type | Dual-piston |
| Rear brake type | Single petal disc |
| Rear brake diameter | Ø 240 mm |
| Rear brake caliper type | Single-piston |
| Front suspension type | Inverted fork with adjustable compression and rebound damping |
| Front suspension diameter | Ø 48 mm |
| Rear suspension type | Uni-Trak, adjustable dual-range (high/low-speed) compression and adjustable rebound damping, and spring preload adjustability |
