Описание
Engine
Engine Type | Liquid-cooled, 4-stroke, single-cylinder |
---|---|
Compression ratio | 12.5:1 |
Valve system | DOHC, 4 valves |
Bore x stroke | 96.0 x 62.1 mm |
Displacement | 449 cm³ |
Fuel System | Fuel injection: 44 mm x 1 |
Lubrication | Forced lubrication, semi‑dry sump |
Starting system | Electric |
Ignition | Digital DC-CDI |
Performance & Transmission
Transmission | 5-speed, return shift |
---|---|
Clutch | Wet, multi disc |
Primary reduction ratio | 2.727 (60/22) |
Gear ratios 1st | 1.750 (28/16) |
Gear ratios 2nd | 1.412 (24/17) |
Gear ratios 3rd | 1.188 (19/16) |
Gear ratios 4th | 1.000 (19/19) |
Gear ratios 5th | 0.875 (21/24) |
Final drive | Chain |
Final reduction ratio | 3.846 (50/13) |
Frame & Dimensions
Frame type | Perimeter, aluminium |
---|---|
Trail | 115 mm |
Wheel travel front | 305 mm |
Wheel travel rear | 307 mm |
Tyre, front | 80/100-21 51M |
Tyre, rear | 120/80-19 63M |
L x W x H | 2,180 x 820 x 1,270 mm |
Steering angle L R | 42° / 42° |
Wheel base | 1,480 mm |
Ground clearance | 345 mm |
Fuel capacity | 6.2 litres |
Seat height | 960 mm |
Curb mass | 112.6 kg |
Brakes & Suspension
Front brake type | Single semi-floating petal disc |
---|---|
Front brake diameter | Ø 270 mm |
Front brake caliper type | Brembo dual-piston |
Rear brake type | Single petal disc |
Rear brake diameter | Ø 240 mm |
Rear brake caliper type | Single-piston |
Front suspension type | Inverted fork with adjustable compression and rebound damping |
Front suspension diameter | Ø 49 mm |
Rear suspension type | Uni-Trak, adjustable dual-range (high/low-speed) compression and adjustable rebound damping, and spring preload adjustability |
